70.6002

Basic parameter:

Material::6063-T56063 T5 corrosion-resistant aluminum housing & die-cast Zinc alloy end cap.

Anti-aging waterproof silicone gasket;

Nickel plated brass waterproof cable gland;

3mm clear safety glass or UVPC diffuser.

Finishing:Anodized aluminum finishing or powder coating;

Control:ON-OFF / DMX512

Control Accuracy:16bit

Voltage:24V DC

Protection class:Ⅲ

Installation:

Ambient temperature: -30°C~ +50°C;

Ambient humidity:10-95%RH;

Surface temperature:≤ 65℃@45℃

Single Color: 2x 0.09m length 2-cores cables with waterproof connector;

DMX512 compatible: 2x0.09m length 5-cores φ7.6mm cables with waterproof connector;

Nickel plated brass waterproof cable gland

Installation in Low Lying area is prohibited,

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
