50.7013

Basic parameter:

Material:ADC12 corrosion-resistant aluminum connection part;

            6063 T5 corrosion-resistant aluminum housing & pole;
            304# stainless steel external fasten screw;
            Silicone glass sealant sealing;

            304# stainless steel external fasten screw;

            Silicone glass sealant sealing;

Finishing: Double layers of UV-resistant polyester powder coating
Installation:Ambient temperature: -30˫։ +50˫ ;
                Non-dimmable: 1x 3-cores Ø7.5mm power supply
                cable,cable will be cable 0.3m longer than the pole;
                Nickel plated brass waterproof cable gland
                Optional Height of Pole: 3000mm/3500mm

Packaging: Net fittings weight: 10kg(H=3000mm)
               Out carton: Wrapping with bubble cotton




Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
50.7013.A6V220H3000 9W Asymmetric 80°x135° 2200K-5700K ON/OFF 630lm /
50.7013.A9V220H3500 15W Asymmetric 80°x135° 2200K-5700K ON/OFF 1050lm /
