70.6006

Basic parameter:

Material:Corrosion-resistant aluminum housing & PC end cap;
            Opal PC diffuser;
            304 stainless steel external fasten screws;
Finishing:Double layers of UV-resistant polyester powder coating;
Installation:Ambient temperature: -30℃~ +50℃ ;
                Single Color: 2x 0.09m length 2-cores cables with
                waterproof connector;
                DMX512 compatible: 2x 0.09m length 5-cores Ø7.6mm
                cables with waterproof connector;
                Nickel plated brass waterproof cable gland
                Installation in Low Lying area is prohibited;
Packaging:Net Weight: 0.6kg
                1050x400x250mm(32pcs/ctn)

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
70.6006.D48V24L1000 12W 160° 2200K-5700K ON/OFF 505lm /
70.6006.D48CV24L1000 12W 160° 2200K-5700K DMX512 503lm /
70.6006.E48SV24L1000 12W 160° RGBW DMX512 252lm /
