10.0732

Basic parameter:

Material:304# stainless steel housing & recessed box;
            Anti-aging waterproof silicone gasket;
            Nickel brass cable gland
            8mm clear safety glass;
Finishing:Stainless steel
Installation:Ambient temperature: -30℃~ +50℃ ;
                Single Color: 1x 0.5m length 2-cores Ø7.0mm power supply
                cable;
                DMX512 compatible: 1x 0.5m 6-cores Ø7.5mm data cables.
                Nickel plated brass waterproof cable gland
Packaging: Net weight: 0.58kg
                Outer carton: 420x260x220mm (48pcs/ctn)

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0732.D6V24 1.5W 120° 2200K-5700K ON/OFF 85lm /
10.0732.D6CV24 1.5W 120° 2200K-5700K DMX512 85lm /
10.0732.E6SV24 1.5w 120° RGBW DMX512 45lm /
10.0732.A1V24 3W 120° 2200K-5700K ON/OFF 120lm /
10.0732.A1CV24 3W 5°/8°/14°/20°/30°/40°/60° 2200K-5700K DMX512 117lm /
  • LED inground mounted luminaire CE.zip

    Document size:

  • 10.0732 chips CREE-3030.pdf

    Document size:

  • 10.0731&10.0732.pdf

    Document size:
