10.0731

Basic parameter:

Material:304# stainless steel housing & recessed box;
            Anti-aging waterproof silicone gasket;
            Nickel brass cable gland
            8mm clear safety glass;
Finishing:Stainless steel
Installation:Ambient temperature: -30℃~ +50℃ ;
                Single Color: 1x 0.5m length 2-cores Ø7.0mm power supply
                cable;
                DMX512 compatible: 1x 0.5m 6-cores Ø7.5mm data cables.
                Nickel plated brass waterproof cable gland
Packaging:Net weight: 0.3kg
               Outer carton:420x260x220mm (48pcs/ctn)

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0731.D4V24 0.6W 120° 2200K-5700K ON/OFF 32lm /
10.0731.D4CV24 0.6W 120° 2200K-5700K DMX512 32lm /
10.0731.E4SV24 0.6W 120° RGBW DMX512 18lm /
10.0731.A1V12 1.5w 12°/20°/30°/40° 2200K-5700K ON/OFF 76lm /
