10.0712

Basic parameter:

Material:304# stainless steel housing & recessed box;
            Anti-aging waterproof silicone gasket;
            Nickel brass cable gland;
            12mm clear safety glass;
Finishing:Stainless steel
Installation:Ambient temperature: -30℃~ +50℃ ;
Single Color: 1x 0.5m length 2-cores Ø7.0mm power supply
cable;
DMX512 compatible:1x 0.5m 6-cores Ø7.5mm data cables.
Nickel plated brass waterproof cable gland
Packaging:Net weight: 0.62kg
               Outer carton: 420x260x220mm (48pcs/ctn)


Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0712S.D3V12 1.2W 10x90° 2200K-5700K ON/OFF 39lm /
10.0712S.D3CV12 1.2W 10x90° 2200K-5700K DMX512 38lm /
10.0712D.D6V24 2W 2-10x90° 2200K-5700K DMX512 90lm /
10.0712D.D6CV24 2W 2-10x90° 2200K-5700K DMX512 88lm /
