10.0711

Basic parameter:

Material:304# stainless steel housing & recessed box;
            Anti-aging waterproof silicone gasket;
            Nickel brass cable gland;
            8mm clear safety glass;
Finishing:Stainless steel
Installation:Ambient temperature: -30℃~ +50℃ ;
                Single Color: 1x 0.5m length 2-cores Ø7.0mm power supply
                cable;
                DMX512 compatible:1x 0.5m 6-cores Ø7.5mm data cables.
                Nickel plated brass waterproof cable gland
                Packaging:Net weight: 0.3kg
Outer carton:420x260x220mm (48pcs/ctn)

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0711S.D1V12 0.5W 10x90° 2200K-5700K ON/OFF 32lm /
10.0711S.D1CV12 0.5W 10x90° 2200K-5700K DMX512 30lm /
10.0711D.D2V12 0.8W 2-10x90° 2200K-5700K ON/OFF 27lm /
10.0711D.D2CV12 0.8W 2-10x90° 2200K-5700K DMX512 25lm /
