50.7009

Basic parameter:

- Material: ADC12 corrosion-resistant aluminum housing and mounting base

                 Extruded aluminum lamp pole

                 304 stainless steel external fasten screws

                 3mm clear safety glass


- Finishing: Double layers of DUPONT UV-resistant polyester powder coating


- Installation: Ambient temperature:-30℃~+45℃;

                    Single color: 1x 3-cores Ø7.5mm power supply cable,

                    cable length is 0.3m longer than the pole

                    Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
50.7009.A4V220H700 10.5W Asymmetric 70x135° 2200K-5700K ON/OFF 700Lm /
50.7009.A4V24H700 8W Asymmetric 70x135° 2200K-5700K ON/OFF 700Lm /
