80.8035

Basic parameter:

- Material: 316L stainless steel housing

                 316 stainless steel external fasten screws;

                 Anti-aging waterproof silicone gasket;

                 5mm clear safety glass


- Finishing: Stainless steel


- Installation: Ambient temperature: -30℃~+45℃;

                    Tiltable: 0~90°

                    Rotation angle: 0~350°

                    Single color: 1x3m length 2coresф7.5mm power supply cable

                    DMX512 controllable: 1x3m length 2coresф7.5mm power supply cable

                    2x3m length 4coresф6.5mm signal supply cable

                    Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
80.8035.A12V12 30W 10°/15°/40°/60°/20x40° 2200K-5700K ON/OFF 2550lm /
80.8035.A18V12 40W 10°/15°/40°/60°/20x40° 2200K-5700K ON/OFF 3400lm /
80.8035.A18CV12 40W 10°/15°/40°/60°/20x40° 2200K-5700K DMX512 3400lm /
80.8035.E18SV12 40W 10°/15°/25°/40° RGBW DMX512 1400lm /
80.8035.E12SV12 30W 10°/15°/25°/40° RGBW DMX512 1050lm /
