80.8033

Basic parameter:

- Material: 316L stainless steel housing

                 316 stainless steel external fasten screws;

                 Anti-aging waterproof silicone gasket;

                 5mm clear safety glass


- Finishing: Stainless steel


- Installation: Ambient temperature: -30℃~+45℃;

                    Tiltable: 0~90°

                    Rotation angle: 0~350°

                    Single color: 1x3m length 2coresф7.5mm power supply cable

                    DMX512 controllable: 1x3m length 2 cores  ф7.5mm power supply cable

                    2x3m length 4coresф6.5mm signal supply cable

                    Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
80.8033.A6V12 15W 8°/15°/40°/60°/20x40° 2200K-5700K ON/OFF 1270lm /
80.8033.A9V12 20W 8°/15°/40°/60°/20x40° 2200K-5700K ON/OFF 1700lm /
80.8033.A9CV12 20W 8°/15°/40°/60°/20x40° 2200K-5700K DMX512 1700lm /
80.8033.E9SV12 20W 10°/25°/40°/60° RGBW DMX512 700lm /
80.8033.E6SV12 15W 10°/15°/25°/40° RGBW DMX512 525lm /
