Basic parameter:

- Material: Corrosion-resistant aluminum housing & Zinc alloy end cap;

                 3mm clear safety glass

                 Anti-aging waterproof silicone gasket;

                 304 stainless steel mounting brackets  & external fasten screws.

- Finishing: Double layers of DUPONT UV-resistant polyester powder coating

- Installation: Ambient temperature: -30℃~+45℃;

                 Single Color: 2x 0.2m length 2-cores Ø7.0mm cables with waterproof connector;

                 DMX512 controllable: 2x 0.2m length 6-cores Ø7.5mm cables with waterproof connector;

                 Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
70.6012.D48V24L1000 12W 120°/40°/60° 2200K-6500K ON/OFF 1200Lm /
70.6012.D48CV24L1000 12W 120°/40°/60° 2200K-6500K DMX512 dimmable,1/4/8 pixels 1200Lm /
70.6012.D48FV24L1000 9.5W 120°/40°/60° RGB DMX512,1/4/8 pixels 305Lm /
70.6012.D48SV24L1000 6W 120°/40°/60° RGBW DMX512,1/4/8 pixels 360Lm /
70.6012.D24V24L500 6W 120°/40°/60° 2200K-6500K ON/OFF 600Lm /
70.6012.D15V24L300 3.5W 120°/40°/60° 2200K-6500K ON/OFF 600Lm /
70.6012.D12V24L250 3W 120°/40°/60° 2200K-6500K ON/OFF 296Lm /
