60.0506

Basic parameter:

- Material: ADC12 corrosion-resistant die-cast aluminum housing;

                 304 stainless steel external fasten screws;

                 Anti-aging waterproof silicone gasket;

                 3mm clear safety glass


- Installation: Ambient temperature:-30℃~+45℃;


- Cable: Single color: 1x0.4m length 2/3coresф7.0mm power supply cable

              Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
60.0506.A1V24 4W 3°/5°/8°/14°/20°/30°/40°/60° 2200K-5700K ON/OFF 324lm /
60.0506.A1CV24 4W 3°/5°/8°/14°/20°/30°/40°/60° 2200K-5700K DMX512 324lm /
60.0506.A1V220 4W 3°/5°/8°/14°/20°/30°/40°/60° 2200K-5700K ON/OFF 296lm /
