20.4041

Basic parameter:

- Material :ADC12 corrosion-resistant die-cast aluminum housing

                 Anti-UV PC diffuser

                 Anti-aging waterproof silicone gasket:

                 304 stainless steel external fasten screws:


- Finishing: Double layers of DUPONT UV-resistant polyester powder coating


- Installation: Ambient temperature: -30℃~+45℃;

                      Single color: 2x 0.2m length 2-cores Ø7.0mm power supply cable with waterproof connector;

                      DMX512 controllable: 2x 0.2m length 6-cores Ø7.5mm cable with waterproof connector;

                      Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
20.4041.E12FV24 1.5W 150° RGB DMX512 30lm /
20.4041.E12SV24 2W 150° RGBW DMX512 80lm /
20.4041.D6V24 3W 150° 2200K-5700K DMX512 255lm /
20.4041.D6CV24 3W 150° 2200K-5700K DMX512 255lm /
