20.0517

Basic parameter:

- Material: ADC12 corrosion-resistant die-cast aluminum housing

                 Anti-aging waterproof silicone gasket;

                 3mm clear safety glass

                 304 stainless steel external fasten screws;


- Finishing:Double layers of DUPONT UV-resistant polyester powder coating


 - Installation: Ambient temperature: -30℃~+45℃;

                      Single color: 1x 0.4m length 3-cores Ø7.0mm power supply cable

                      DMX512 controllable: 1x 0.4m length 3-cores Ø7.0mm power supply cable;

                      2x0.4m lenght 4-cores Ø6.0mm data cables.

                      Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
20.0517.A10V220 25W 8°/16°/25°/40°/60°/Asymmetric 70 2200K-5700K ON/OFF 1850lm /
20.0517.A10CV220 25W 8°/16°/25°/40°/60°/Asymmetric 70 2200K-5700K DMX512 1850lm /
20.0517.E10SV220 25W 10°/16°/25°/40°/60° RGBW DMX512 950lm /
