20.0506S

Basic parameter:

- Material: ADC12 corrosion-resistant die-cast aluminum housing

                 Anti-aging waterproof silicone gasket;

                 3mm clear safety glass

                 304 stainless steel external fasten screws;


- Finishing: Double layers of DUPONT UV-resistant polyester powder coating


 - Installation: Ambient temperature: -30℃~+45℃;

                     Single color: 1x 0.4m length 3-cores Ø7.0mm power supply cable

                     DMX512 controllable: 1x 0.4m length 3-cores Ø7.0mm power supply cable;

                     2x0.4m lenght 4-cores Ø6.0mm data cables.

                     Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
20.0506S.A12V12 3W 3°/5°/8°/14°/20°/30°/40°/60° 2200K-5700K ON/OFF 243lm /
20.0506S.A1CV212 3W 3°/5°/8°/14°/20°/30°/40°/60° 2200K-5700K DMX512 243lm /
20.0506S.A1V220 4.5W 3°/5°/8°/14°/20°/30°/40°/60° 2200K-5700K ON/OFF 333lm /
