10.0911

Basic parameter:

- Material:ADC12 corrosion-resistant die-cast aluminum housing;

                8mm clear safety glass ;

                anti-aging waterproof silicone gasket;

                304/316 stainless steel cover ring and external fasten screws

                PP Plastic recessed box


 - Finishing:Stainless steel


 -Installation:Ambient temperature:-30℃~+45℃;

                     Single Color:1x 0.5m length 2-cores Ø7.0mm power supply cable;

                     DMX512 controllable:1x 0.5m length 6-cores Ø7.5mm cable;

                     Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0911.A1V12 2W 10°/25°/40°/60° 2700K-5700K ON/OFF 162lm /
10.0911.D3V24 1W 120° 2700K-5700K ON/OFF 20lm /
10.0911.D3CV12 1W 120° 2700K-5700K DMX512 20lm /
10.0911.E3SV12 0.6W 120° RGBW DMX512 10.2lm /
